11.1V 12V 12.6V BMS Battery Protection Board Lithium 3s Bms Module

Image shown is a representation only. Exact specifications should be obtained from the product data sheet.

Part Number:	11.1V 12V 12.6V BMS Battery Protection Board Lithium 3s Bms Module
Manufacturer:
Packing:
D/C:	new+
Description:	11.1V 12V 12.6V BMS Battery Protection Board Lithium 3s Bms Module
Quantity:	9999 Pieces
Delivery Time:	1-2 days
Data sheet:

If you need to get the correct price,Please send your RFQ to info@hfd-ic.com

Introduction

11.1V 12V 12.6V BMS Battery Protection Board Lithium 3s Bms Module best price and fast delivery.

Hengfengda is the distributor for 11.1V 12V 12.6V BMS Battery Protection Board Lithium 3s Bms Module, we have the stocks for immediate shipping and also available for long time supply. Please send us your purchase plan for 11.1V 12V 12.6V BMS Battery Protection Board Lithium 3s Bms Module by email, we will give you a best price according your plan.
Our email: info@hfd-ic.com

Specifications

PRODUCT DESCRIPTION

3S 20A 11.1V 12V 12.6V BMS Module Li-ion Lithium Battery 18650 Charger PCB Protection Board

Product Description:

3 strings of 12.6V lithium battery protection boards
Application: Nominal voltage 3.6V, 3.7V lithium battery (including 18650, 26650, polymer lithium battery)
Product size: 50*16.5*3mm
Product weight: 2.4g
Charging voltage: 12.6V-13.6V Continuous discharge current (upper limit) : 10A (If the heat dissipation environment is not good, please reduce the load current)
Continuous charging current (upper limit) : 5A
Note: The PCB baseboards of 5A and 10A are the same, the difference is that 5A has 2 MOS tubes and 10A has 4 MOS tubes.

Note:

Connect 0V, 4.2V, 8.4V, 12.6V strictly according to the drawing (0V or 12.6V is connected to the wrong burning plate, 4.2V or 8.4V is connected to the wrong plate and does not work). Note 2: When there is a load of brush motor, a non-polar capacitor (25V +, 10uF-100uF) must be connected in parallel to the positive and negative terminals of the motor to prevent the reverse peak voltage generated by the motor from interfering.
